Total Ossicular Replacements

PE Total

PE Total

L = Total Length
FL = Functional Length

Columella O.D.: 0.70

Item No. Length (mm) Qty/Box
TAP 07.09.600 6.00 1
TAP 07.09.700 7.00 1
TAP 07.09.800 8.00 1
PE Offset Total

PE Offset Total

Columella O.D.: 0.65

Item No. Length (mm) Qty/Box
TPL 07.04.600 6.00 1
TPL 07.04.700 7.00 1
TPL 07.04.800 8.00 1
PE Malleable Offset Total

PE Malleable Offset Total

  • Platinum core

Columella O.D.: 0.70 mm

Item No. Length (mm) Qty/Box
TPL 07.03 Total Length (L): 8.00 mm 1
Dense HA Total

Dense HA Total

Columella O.D.: 0.65

Item No. Length (mm) Qty/Box
TAP 07.11.500 5.00 1
TAP 07.11.550 5.50 1
TAP 07.11.600 6.00 1
TAP 07.11.650 6.50 1
TAP 07.11.700 7.00 1
TAP 07.11.750 7.50 1
TAP 07.11.800 8.00 1
Dense HA Offset Total

Dense HA Offset Total

Columella O.D.: 0.70

Item No. Length (mm) Qty/Box
TPL 07.05.500 5.00 1
TPL 07.05.550 5.50 1
TPL 07.05.600 6.00 1
TPL 07.05.650 6.50 1
TPL 07.05.700 7.00 1
TPL 07.05.750 7.50 1
TPL 07.05.800 8.00 1
Dense HA 90° Oval Head Total

Dense HA 90° Oval Head Total

Columella O.D.: 0.75

Item No. Length (mm) Qty/Box
TAP 07.13.500 5.00 1
TAP 07.13.550 5.50 1
TAP 07.13.600 6.00 1
TAP 07.13.650 6.50 1
TAP 07.13.700 7.00 1
TAP 07.13.750 7.50 1
TAP 07.13.800 8.00 1
Dense HA Malleable Total

Dense HA Malleable Total

  • Platinum Wire

Columella O.D.: 0.65

Item No. Length (mm) Qty/Box
TPL 07.07.550 5.50 1
TPL 07.07.600 6.00 1
TPL 07.07.650 6.50 1
TPL 07.07.700 7.00 1
TPL 07.07.750 7.50 1
TPL 07.07.800 8.00 1
PTFE Total

PTFE Total
with Malleable Gold Head and Shaft

  • Trimmable PTFE columella
Item No. Dimensions Qty/Box
TAP 07.46 Total Length (L): 8.00 to 4.50 mm
Head: 3.00 mm
Gold wire O.D.: 0.30 mm
PTFE O.D.: 0.80 mm
1
Dense HA and PTFE Malleable Total

Dense HA and PTFE Malleable Total

  • Platinum Wire

Columella O.D.: 0.65

Item No. Dimensions Qty/Box
TAP 07.40 Total Length (L): 8.00 mm
Head O.D.: 3.50 mm
Platinum Wire O.D.: 0.20 mm
Audio-PE Columella O.D.: 0.75 mm
1
Adjustable Total with Gold Head and Shaft with PTFE Columella

Adjustable Total
with Gold Head and Shaft with PTFE Columella

  • Extendable stem
Item No. Dimensions Qty/Box
TAP 07.48 Total Length (L): 4.00 to 9.00 mm
Head: 3.00 mm
Gold Wire O.D.: 0.30 mm
PTFE O.D.: 0.80 mm
1
Titanium Adjustable Total

Titanium Adjustable Total

  • Extendable stem
Item No. Dimensions Qty/Box
TAP 07.55 Total Length (L): 5.00 to 8.50 mm
Head size: 3.80 x 3.00 mm
1
Titanium Total

Titanium Total

  • Platinum Wire

Columella O.D.: 0.60

Item No. Length (mm) Qty/Box
TAP 07.61.300 3.00 1
TAP 07.61.325 3.25 1
TAP 07.61.350 3.50 1
TAP 07.61.375 3.75 1
TAP 07.61.400 4.00 1
TAP 07.61.425 4.25 1
TAP 07.61.450 4.50 1
TAP 07.61.475 4.75 1
TAP 07.61.500 5.00 1
TAP 07.61.525 5.25 1
TAP 07.61.550 5.50 1
TAP 07.61.600 6.00 1
TAP 07.61.650 6.50 1
TAP 07.61.700 7.00 1
TAP 07.61.750 7.50 1
TAP 07.61.800 8.00 1
Dense HA Telescopic Total Trimmable

Dense HA Telescopic Total Trimmable

Piston O.D.: 0.80

Item No. Length (mm) Qty/Box
TAP 07.18.500 5.00 min / 5.70 max 1
TAP 07.18.550 5.50 min / 6.20 max 1
TAP 07.18.600 6.00 min / 6.70 max 1
TAP 07.18.650 6.50 min / 7.20 max 1
TAP 07.18.700 7.00 min / 7.70 max 1
TAP 07.18.750 7.50 min / 8.20 max 1
TAP 07.18.800 8.00 min / 8.70 max 1
Titanium Adjustable Total and Partial Universal

Titanium Adjustable Total and Partial Universal

Piston O.D.: 0.80

Item No. Length (mm) Qty/Box
TPL 07.57 Partial:
Minimum length: 3.50 mm
Columella O.D.: 1.80 mm
Columella I.D.: 1.20 mm

Total:
Maximum length: 8.50 mm
Columella O.D.: 0.70 mm
1
Titanium Adjustable Total

Titanium Adjustable Total

  • Extendable Stem
Item No. Length (mm) Qty/Box
TAP 07.63 Total Length (L): 3.00 to 8.00 mm
Head size: 3.50 x 2.50 mm
1
Titanium Trimmable Total with Separate Head

Titanium Trimmable Total with Separate Head

  • Trimmable in 1 mm increments
Item No. Length (mm) Qty/Box
11300 7.5 to 3.50 mm 1
11400 7.0 to 3.00 mm 1
Titanium Total Fixed Length

Titanium Total Fixed Length
with Adjustable Centered Head

Item No. Length (mm) Qty/Box
11930* 3.00 1
11935 3.50 1
11940 4.00 1
11942 4.25 1
11945 4.50 1
11947 4.75 1
11950 5.00 1
11960 6.00 1
11965 6.50 1
11970 7.00 1
*Fixed head
Titanium Total Fixed Length with Adjustable Offset Head

Titanium Total Fixed Length
with Adjustable Offset Head

  • Trimmable PTFE columella
Item No. Length (mm) Qty/Box
11830* 3.00 1
11835 3.50 1
11840 4.00 1
11842 4.25 1
11845 4.50 1
11847 4.75 1
11850 5.00 1
11860 6.00 1
11865 6.50 1
11870 7.00 1
*Fixed head
Titanium Malleable Trimmable Totalwith Adjustable Head and Separate Shoe

Titanium Malleable Trimmable Total
with Adjustable Head and Separate Shoe

  • Trimmable PTFE columella
Item No. Length (mm) Qty/Box
11500 7.50 to 2.80 mm 1
11600 7.30 to 2.30 mm 1
