Incus

Dense HA Incus Strut

Dense HA Incus Strut

L = Total Length
FL = Functional Length

Columella O.D.: 2.00

Item No. Length (mm) Qty/Box
INCUS 07.17.275C 2.75 1
INCUS 07.17.325C 3.25 1
INCUS 07.17.375C 3.75 1
INCUS 07.17.490C 4.90 1
Titanium Incus Strut

Titanium Incus Strut

Columella O.D.: 2.00 / Columella I.D.: 1.20

Item No. Length (mm) Qty/Box
PAP 07.56.300 3.00 1
PAP 07.56.400 4.00 1
PAP 07.56.500 5.00 1
Dense HA Partial Incus ISJ

Dense HA Partial Incus ISJ

Item No. Dimensions Qty/Box
INCUS 07.32 L = 2.50 mm H= 1.60 mm 1
Titanium Incus Grip Replacement

Titanium Incus Grip Replacement

Item No. Dimensions Qty/Box
PAP 07.53 Total length: 1.90 mm
Thickness: 0.05 mm
1
Porous HA Adjustable Partial with Malleus Slot

Porous HA Adjustable Partial with Malleus Slot

  • Platinum wire

Columella O.D.: 2.10

Item No. Length (mm) Qty/Box
PAP 07.34.400 4.00 1
PAP 07.34.450 4.50 1
PAP 07.34.500 5.00 1
PAP 07.34.550 5.50 1
PAP 07.34.600 6.00 1
Dense HA and PE Incus Replacement with Malleable Head

Dense HA and PE Incus Replacement with Malleable Head

Item No. Dimensions Qty/Box
PAP 07.43 Total Length (L): 6.50 mm
Head: 3.50
Platinum wire O.D.: 0.25
Columella external O.D.: 2.20
1

Porous HA Head with Malleus Slot, PTFE Shaft

Item No. Dimensions Qty/Box
PAP 07.36 Total Length (L): 6.50 to 3.00 mm
Head O.D.: 3.50 mm
Platinum Wire O.D.: 0.25 mm
PTFE Columella O.D.: 2.10 mm
1
Porous HA and PE Adjustable Partial with Malleus Slot

Porous HA and PE Adjustable Partial with Malleus Slot

Item No. Dimensions Qty/Box
PAP 07.38 Total Length (L): 6.50 to 3.00 mm
Head O.D.: 3.50 mm
Platinum Wire O.D.: 0.25 mm
Audio-PE Columella O.D.: 2.10 mm
1
Porous HA/PTFE/Titanium Universal Total/Partial with Malleus Hook

Porous HA / PTFE / Titanium Universal Total / Partial with Malleus Hook

Item No. Dimensions Qty/Box
TPL 07.59 Partial: Minimum Length: 3.50
Columella outside O.D.: 1.30
Total: Maximum length: 7.50
Columella O.D.: 0.60
1
Porous HA/Titanium Incus with Malleus Slot

Porous HA/Titanium Incus with Malleus Slot

Columella O.D.: 1.30 / Columella I.D.: 1.10

Item No. Length (mm) Qty/Box
PAP 07.66.100 1.00 1
PAP 07.66.125 1.25 1
PAP 07.66.150 1.50 1
PAP 07.66.175 1.75 1
PAP 07.66.200 2.00 1
PAP 07.66.225 2.25 1
PAP 07.66.250 2.50 1
PAP 07.66.300 3.00 1
PAP 07.66.325 3.25 1
PAP 07.66.350 3.50 1
PAP 07.66.400 4.00 1
PAP 07.66.450 4.50 1
PAP 07.66.500 5.00 1
Porous HA / Titanium Extensible Incus with Malleus Slot

Porous HA / Titanium Extensible Incus with Malleus Slot

  • Extendable Stem
Item No. Dimensions Qty/Box
PAP 07.68 Total Length (L): 2.50 to 5.00 mm
Head size: 3.50 x 2.50 mm
1
Porous HA / Titanium Extensible Incus with Malleus Slot

Porous HA / Titanium Extensible Incus with Malleus Slot

  • Extendable Stem
Item No.

Extended

Length (mm)

Compressed

Length (mm)

Qty/Box
PAP 07.60.250 2.50 1.80 1
PAP 07.60.300 3.00 2.30 1
PAP 07.60.350 3.50 2.80 1
PAP 07.60.400 4.00 3.30 1
PAP 07.60.450 4.50 3.80 1
PAP 07.60.500 5.00 4.30 1
Porous HA / Titanium Replacemnt Incus with Malleus Slot

Porous HA / Titanium Replacemnt Incus with Malleus Slot

  • Extendable Stem
Item No. Length (mm) Qty/Box
PAP 07.72 2.0 to 5.0 mm 1
