Incus Stapes

Titanium/PTFE Trimmable Incus Stapes

Titanium/PTFE Trimmable Incus Stapes

L = Total Length
FL = Functional Length

Item No. Description Qty/Box
TAP 07.52 Total Length: 6.25 to 4.50 mm
Titanium F67 Gr.2
Thickness: 0.05 mm
PTFE O.D.: 0.60 mm
1
Dense HA I-S 'Marpla' by E. Garcia Ibanez - Wehrs Type

Dense HA I-S "Marpla" by E. Garcia Ibanez - Wehrs Type

Item No. Description Qty/Box
TAP 07.54 Total Length: 8.00 mm
Head: 4.00 mm
Columella width: 1.00 x 0.80 mm
1
Dense HA and PE I-S Prosthesis with Malleable Head

Dense HA and PE I-S Prosthesis with Malleable Head

Item No. Description Qty/Box
TAP 07.42 Total Length: 8.00 mm
Head: 3.50 mm
Platinum Wire O.D.: 0.20
Audio-PE O.D.: 0.75
1
Porous HA and PE Malleable I-S with Malleus Slot

Porous HA and PE Malleable I-S with Malleus Slot

Item No. Description Qty/Box
TAP 07.37 Total Length (L): 8.00 to 3.25 mm
Head O.D.: 3.50 mm
Platinum Wire O.D.: 0.20 mm
Audio-PE Columella O.D.: 0.60 mm
1
Porous HA and PTFE Malleable Incus Stapes with Malleus Slot

Porous HA and PTFE Malleable Incus Stapes with Malleus Slot

Item No. Description Qty/Box
TAP 07.35 Total Length (L): 8.00 to 3.25 mm
Head O.D.: 3.50 mm
Platinum Wire O.D.: 0.20 mm
Audio-PE Columella O.D.: 0.60 mm
1
Porous and Dense HA Malleable I-S

Porous and Dense HA Malleable I-S

• Platinum wire
• Lower end columella O.D.: 0.65

Item No. Length (mm) Qty/Box
TAP 07.33.550 5.50 1
TAP 07.33.600 6.00 1
TAP 07.33.650 6.50 1
TAP 07.33.700 7.00 1
TAP 07.33.800 8.00 1
TITANIUM / Porous HA Adjustable I-S with Malleus Slot

TITANIUM / Porous HA Adjustable I-S with Malleus Slot

• Extended Stem

Item No. Length (mm) Qty/Box
TAP 07.67 Total Length (L): 4.00 to 8.00 mm
Head size: 3.50 x 2.50 mm
1
TITANIUM / Porous HA Adjustable I-S with Malleus Hook

TITANIUM / Porous HA Adjustable I-S with Malleus Hook

Item No. Length (mm) Qty/Box
TAP 07.58 Total Length (L): 5.00 to 8.50 mm
Head size: 3.50 x 2.50 mm
Columella O.D.: 0.60 mm
1
TITANIUM / Porous HA I-S with Malleus Slot

TITANIUM / Porous HA I-S with Malleus Slot

Columella O.D.: 0.60

Item No. Dimensions Qty/Box
TAP 07.65.300 3.00 1
TAP 07.65.325 3.25 1
TAP 07.65.350 3.50 1
TAP 07.65.375 3.75 1
TAP 07.65.400 4.00 1
TAP 07.65.425 4.25 1
TAP 07.65.450 4.50 1
TAP 07.65.475 4.75 1
TAP 07.65.500 5.00 1
TAP 07.65.525 5.25 1
TAP 07.65.550 5.50 1
TAP 07.65.600 6.00 1
TAP 07.65.650 6.50 1
TAP 07.65.700 7.00 1
TAP 07.65.750 7.50 1
TAP 07.65.800 8.00 1
TITANIUM / PTEF / HAP Spring Total

TITANIUM / PTEF / HAP Spring Total

  • Wire O.D.: 0.20 mm
  • PTFE O.D.: 0.6 mm
Item No. Extended
Length (mm)
Compressed
Length (mm)
Qty/Box
TAP 07.71 8.00 - 4.00 7.30 - 3.30 1
